Adapter switch. za šinu DC 12 V 40W MDR-40-12

Osnovne značajke
Features
• Direct assembly on DIN Rail
• Enclosed case, Touch-guard screw terminals
• Universal input
• Overload protection, current limiting, auto recovery
• Protections: short circuit/over load/over voltage
• Power-on LED display
• Low no load power...
149,00kn
Dostupno manje od 5 kom
Dosegli ste maksimum raspoloživosti - 1

Jednokratno plaćanje:
  • Internet bankarstvo (virman)
  • Pouzećem - plaćanje gotovinom dostavljaču kod isporuke paketa
  • Maestro, MasterCard, Visa, Visa Premium
Obročno plaćanje:
  • MasterCard ZABA do 24 rate
  • Visa Premium do 10 rata
Adapter switch. za šinu DC 12 V 40W  MDR-40-12
149,00kn
Opis
Features
• Direct assembly on DIN Rail
• Enclosed case, Touch-guard screw terminals
• Universal input
• Overload protection, current limiting, auto recovery
• Protections: short circuit/over load/over voltage
• Power-on LED display
• Low no load power consumption
• DC OK relay contact
Technical Specifications

Input Voltage: 85...264V AC (47...63Hz)
120...370V DC
Input Inrush Current, Max.:60A
Leakage Current, Max.:1mA
Output Voltage Adjustment:+20%
No Load Power Consumption, Max.:0,75W
Over Load Protection:105...150%
Withstand Voltage
I/P-O/P: 3000V AC
I/P-FG: 2000V AC
O/P-FG: 500V AC
Operating Temperature:-20...+70°C
Weight: 300g
I/P = Input, O/P = Output, FG = Frame Ground


Part Nr. UAIAPADUAURN h
[V][A][W][%][mVp-p][%]
MDR-40-5 50...63028078
MDR-40-12 120...3,3340112086
MDR-40-24 240...1,740,8115088
MDR-40-48 480...0,8339,8120088

UA = Output Voltage, IA = Output Current Range, PA = Output Power,
DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Efficiency
